CMP Pro-Loc 500 SQR jet body

This new-generation "SQR" socket from CMP fits all of the CMP Pro-Loc 500 jets. It is attached to the spa shell and the jet is snapped-in.

No nuts or gaskets with the SQR system: a grommet (to be purchased separately) locks the socket in place and seals it by radial force (traditional jets consisting of a nut, gasket and and comp ring seal by compression).

The socket is clear, so you can combine massage and LED lighting (with the addition of LED port clip) as you wish.

The water flow through the socket draws in air through the Venturi effect, which adds bubbles to the water jet and increases the power of the massage. The air inlet of each nozzle is normally connected to a manifold, and then to a valve, so that the air/water mixture in the jets can be modified.

Despite very great similarities and identical dimensions, this socket is not interchangeable with the Typhoon 500 white model from CMP.

Dimensions
Drilling diameter : 93 mm
Diffuseur length : 136 mm
Face diameter : 120 mm

Connection
Water: 3/4 inch pipe
Air: 3/8 inch pipe

Part numbers
CMP : 29252-089-000
